List of Hologram Machines

We supply whole set hologram machines including holographic master shooting system, electronic forming machine, hologram embosser, Lamination & coating machine and die-cutting machine. Affordable Hologram Machinery   Hologram Sticker Production Photoes    Hologram Hot Stamping Machinery and Project

Holograms have 2D/3D hologram, Dot-matrix hologram, 3D hologram and recombination of them to enhance security. Such features as hidden texts, micron text, kinematic Guilloche lines, true color/photo, flip-flop/switching/multi-channels, solid white, flash fight, will improve security too. The hologram has most security features conbination will be high security.

1. 2D/3D Master Shooting System

2D/3D master shooting lab includes Microprocessor-Controlled Automatic Positioning Platform and controller, Optical Table, He-Cd Laser, whole set Optics, Silver Coatings and other technology transfer.

2. Dot-matrix Master Shooting System

Whole set of dot-matrix holographic master shooting machines includes high precision dot-matrix platform, 3 color separation optic head, platform controller, PC and software, Silvering, He-Cd Laser.

3. Holographic master Recombination Machine

To recombine small master into big master.

Small recombiner can recombine upto size 250mm*250mm.

Big recombiner can recombine upto size 1500mm*650mm.

4. Electronic Forming Machine

Electronic forming machine duplicates nickel operation shim from hologram mother shim for next process hologram embossing. Then we fix nickel hologram operation onto embosser's cylinder and emboss hologram image onto metallized PET film

5. Narrow Hard Web Embosser

Narrow web hard embosser is the machine to emboss hologram image onto base material such as aluminum metallized PET film, transparent PET film, aluminum foil,etc. It's very simple manufacturing process with very low cost. Hologram image is compressed by three cylinder with air pressure without ink.

a. Hard Embosser Model 1

b. Hard Embosser Model 2

6. Hologram Lamination

To laminate silicon paper(liner) and hologram film together by adhesive. Adehensive (usually, solvent based) is same adhesive for normal self-sticker.

7. Hot Melt Adhensive Coating Machine

To coat hot melt adhesive on hot stamping foil.

8. Wide Web Soft Embosser

To emboss transparent hologram film in wide web width up to 1200mm. The base material can be BOPP, PET and PVC film.

9. Hologram Sticker Automatic Die-cutting Machine

This machine die-cut hologram sticker precisely and fast in roll format with slitter.
